Navini Networks, Inc. Ripwave MX Modem User Guide
The Signal Stren
ignal Quality B
gth and
ars,
ontinued
ow to Increase
e Strength and
uality of the
ignal
e
ng
strength of the signal. Green lines indicate an excellent signal.
Orange lines indicate a good signal while red lines indicate a weak
signal.
The Signal Quality bar area graphically represents the Signal-to-
Noise Ratio (SNR) received by your Modem. Again, the quality of
the signal is represented by a group of colored bars. The higher the
pile of bars goes, the better the SNR of the signal. The color of the
bars also gives an indication of the quality of the signal. Green
lines indicate an excellent signal or an SNR greater than 21.
Orange lines indicate a good signal or an SNR greater than or equal
13 but less than or equal to 21. Red lines indicate a weak signal
r an SNR less than 13.
g it closer to a window, to a
igher location, away from other wireless devices (microwave
vens, cordless phones), and away from metal objects (shelves, file
abinets). As you reposition your Modem, watch the Signal
trength and Signal Quality bars on the NavDiag screen. Place
our Modem in the location where you receive the most green
gnal strength and quality bars.
er time. The graphs cover the last minute and are updated
very second. Read the graphs from right to left. The right side of
e graph represents the most recent status of your Modem.
S
c
H
th
Q
S
The History Graphs
In particular, the Signal Strength bar area graphically represents th
strength of the synchronization signal your Modem is receivi
from BTS. The strength of the signal is represented by a group of
colored bars. The higher the pile of bars goes, the stronger the
signal is. The color of the bars also gives an indication of the
to
o
To increase the strength and quality of the signal, change the
ocation of your Modem. Try movin
l
h
o
c
S
y
si
The History graphs plot the change in signal strength and signal
uality ov
q
e
th
20
060825_pv1.6_Ripwave-MX Modem User Guide_40-00382-00Rc(4.5)
