Navini Networks, Inc. Ripwave MX Modem User Guide
3333
ADDENDUM 1: oting
- For Use With All nostics Software -
C Operating Systems
rior to installing the Navini iagnostics software, please check to insure that the PC Operating System
eets the criteria given in the table below. If these criteria are not met, unpredictable problems may
ccur as a result of installatio It is recommended that the user have the latest Windows
c
updates
stalled prior to installing the avini Diagnostics software.
Ripwave
™
-MX Modem - PC Troublesho
ipwave-MX LMX Modems and Navini Diag
R
P
P D
m
o n.
in N
Operating System Ethernet interface Notes
Win 2000 Supported 1
Win XP Supported 2
Note 1: Requires Service Pack
ote 2: To load the Navini Diagnostics software, the user MUST have Administrative privileges.
Ethernet Interface
The Ethernet Modem may be connected to a PC via an Ethernet connection. Also, it is possible to
connect multiple PC devices to a single Modem. The multi-PC configuration is transparent to the PC
users and is analogous to a multi-PC configuration on a normal Ethernet LAN. Check with your Service
Provider if multiple IP addressing is required for your particular configuration. The distinct advantage of
the Ethernet Modem is that it connects to any device that has an Ethernet interface. This makes it ideal
for small businesses that have a mix of devices, such as Unix machines, Apple Computers, etc. IP
addresses can be assigned to the devices dynamically via a DHCP server, or as Fixed IP assignments, or
Point-to-Point Protocol Over Ethernet (PPPoE).
Multiple Interface Environments
When a PC has an internal interface (for example, a Wireless Ethernet interface) in addition to the LMX
Modem, you should do the following:
• If the wireless connection is not required, disable the internal wireless connection
• If the built-in wireless connection is required for local networking and wireline Ethernet is used via
the LMX Modem for Internet connection, change the interface metric configuration so that the
wireline interface’s default gateway is used. (See your Operating System’s User Guide.)
Routers
Neither the Navini LMX Monitor nor the Navini Diagnostics software will work if it goes through a
router.
1
N
33
060825_pv1.6_Ripwave-MX Modem User Guide_40-00382-00Rc(4.5)
