E – 38
Communication Speed:
This feature sets the baud rate of the PC Control port (Mini DIN 8
Pin).
It supports data rates from 4800 to 38400 bps.
The default is 38400 bps. Select the appropriate baud rate for your
equipment to be connected.
Default Source Select:
You can set the projector to default to any one of its inputs each
time the projector is turned on.
Last.............. Sets the projector to default to the previous or last active
input each time the projector is turned on.
Auto ............. Searches for an active source in order of RGB → Video → S-
Video → PC Card Viewer → RGB and displays the first found
source.
Select ........... Displays the selected source input every time the projector is
started up. Select an input from the pull-down menu.
[Page4]
Auto Adjust (RGB Only):
When "Auto Adjust" is set to "On", the projector automatically de-
termines the best resolution for the current RGB input signal to
project an image using NEC's Advanced AccuBlend Intelligent Pixel
Blending Technology.
The image can be automatically adjusted for position and stability;
"Horizontal Position", "Vertical Position", "Clock", "Phase", and
"Resolution."
On ................ Automatically adjusts image "Horizontal Position", "Vertical
Position", "Clock", "Phase" and "Resolution".
Off................ User can adjust the image display functions ("Horizontal Po-
sition", "Vertical Position", "Clock", "Phase" and "Resolution")
manually.
Auto Start:
Turns the projector on automatically when the power cable is in-
serted into an active power outlet. This eliminates the need to al-
ways use the "Power" button on the remote control or projector cabi-
net.
Power Management:
When this option is on and there is no RGB input for five minutes or
more, the projector will automatically turn itself off.
Power Off Confirmation:
This option determines whether a confirmation dialog for turning off
the projector will appear or not.
NOTE: When the confirmation message is displayed, you must be in the
Projector mode to operate your projector using the remote control. If not,
press the PJ button on the remote control to change your projector to the
Projector mode. The button lights to indicate that you are in the Projector
mode.
Keystone Save:
This option enables you to save your current keystone settings.
Saving your change once affects all sources. The changes are saved
when you turn off the projector.
Clear Lamp Hour Meter:
Resets the lamp clock back to zero. Pressing this button appears a
confirmation dialog box. To reset the lamp usage hour, press "OK".
NOTE: The projector will turn off and go into standby mode after 1100 hours
(up to 2200 hours in Eco mode) of service. If this happens, press the "Help"
button on the remote control for ten seconds to reset the lamp clock back
to zero. Do this only after replacing the lamp.
[Page5]
