E – 52
6. SPECIFICATIONS
This section provides technical information about the MultiSync LT155/LT154 Projector’s performance.
Model Number LT155/LT154
Optical
LCD Panel 0.9” p-Si TFT active-matrix, 1024ן768 dots
With Micro Lens Array (LT155)
Lens Manual zoom, manual focus
F2.0 – 2.3 f=36.5 – 42 mm
Lamp 130W NSH lamp (110W in Eco mode)
The lamp, under normal operating conditions, is warranted for 1000 hours of operation time within 6 months.
Image Size 25 – 300 inches (0.64 – 7.62 m) diagonal
Projection Distance 3.7 – 40.1 ft (1.1 - 12.2 m)
Electrical
Inputs Video (NTSC / PAL / PAL60 / SECAM / NTSC4.43)
Horizontal Frequency : 15 – 100 kHz (RGB : 24 kHz or over)
Vertical Frequency : 50 – 120 Hz
Video Bandwidth RGB: 80 MHz
Color Reproduction Full color, 16.7 million colors simultaneously.
Horizontal Resolution 500 TV lines : NTSC / PAL / NTSC4.43 / YCbCr
350 TV lines : SECAM
RGB 1024 dots horizontal, 768 dots vertical
Power Requirement 100 – 120 / 200 – 240 VAC, 50 / 60 Hz
Input Current 2.2 A (100 – 120 VAC) / 1.0A (200 – 240 VAC)
Mechanical
Dimensions
8.1" (W)ן2.5" (H)ן10.5" (D) / 207mm (W)ן63mm (H)ן266mm (D) (not including lens and feet)
Net Weight 4.9 lbs / 2.2 kg
Environmental Considerations
Operational Temperatures: 32˚ – 95˚F (0˚ to 35˚C), 20 – 80% humidity
Storage Temperatures: 14˚ – 122˚F (-10˚ to 50˚C), 20 – 80% humidity
Regulations UL Approved (UL 1950, CSA 950)
Meets DOC Canada Class B requirements
Meets FCC Class B requirements
Meets AS/NZS3548 Class B
Meets EMC Directive (EN55022, EN55024, EN61000-3-2, EN61000-3-3)
Meets Low Voltage Directive (EN60950, TUV GS Approved)
LCD panels are inherently susceptible to bad pixels.
The LCD panel may have pixel failures at the rate of 0.01% or less.
We provide information about our projectors through the World Wide Web at http://www.nec-pj.com/
The specifications are subject to change without notice.
