English-7
English
1
POWER button
Switches the power on/off.
2
INPUT button*
Selects which input signal, [DVI], [VGA], [RGB/HV], [HDMI],
[DVD/HD], [VIDEO], [TV] or [S-VIDEO].
[S-VIDEO] is enabled by selecting the “SEPARATE” mode in
the OSD or by having the “S-VIDEO” cable connected with
the “S-VIDEO” signal present and selecting “PRIORITY”
MODE. See page 28.
3
PICTURE MODE button
Selects from picture mode, [HIGHBRIGHT], [STANDARD],
[sRGB], [CINEMA]. See page 22.
HIGHBRIGHT: for moving images such as DVD
STANDARD: for images
sRGB: for text based images
CINEMA: for movies.
4
SIZE button
Selects picture size, [FULL], [NORMAL], [WIDE] and [ZOOM].
See page 22.
5
SOUND button*
Artificial surround sound.
6
AUDIO INPUT button*
Selects from input audio source [IN1], [IN2], [IN3], [HDMI],
[TV].
7
KEYPAD
Press to set and change passwords, change channel and
set REMOTE ID.
8
ENT button
Sets channels.
9
DISPLAY button
Turns on/off the information OSD. See page 22.
10
MENU button
Turns on/off the menu mode.
11
AUTO SETUP button
Enters auto setup menu. See page 24.
12
EXIT button
Turns to previous menu with OSD menu.
13
UP/DOWN button
Acts as
button to move the highlighted area up or
down to select the adjustment with OSD menu.
Small screen which adjusted “PIP” mode moves up or down.
14
MINUS/PLUS (+/-) button
Increases or decreases the adjustment with OSD menu.
Small screen which adjusted “PIP” mode moves left or right.
15
SET button
Makes selection.
16
VOLUME UP/DOWN button
Increases or decreases audio output level.
17
CH +/- button*
Moves channel up or down.
18
CH RTN button*
Returns to previous channel.
19
MUTE button*
Turns on/off mute function.
20
STILL button
ON/OFF button: Activates/deactivates on/off still picture
mode.
STILL CAPTURE button: Captures still picture.
21
PIP (Picture In Picture) button
ON/OFF button: Toggle switches between PIP, POP, side-
by-side (aspect) and side-by-side (full). See page 26.
INPUT button: Selects the “picture in picture” input signal.
CHANGE button: Replaces to the main picture and sub
picture.
*: The product you purchased may not have this feature.
Wireless Remote Control
(The product you purchased has one of these remote controls)
DVI VGA RGB/HV HDMI DVD/HD VIDEO TV
DVI - - - -
VGA - - - -
RGB/HV - - - -
HDMI - - - -
DVD/HD -
VIDEO --
TV --
Sub picture
Main
