E–19
RGB
INPUT
OUTPUT
AUDIO
IN
INOUT
OUT
PC-CONTROL S-VIDEO VIDEO
RGB INPUT
AUDIO
1
O
N
D
I
P
2
34
56
To connect to a Macintosh, simply:
1. Turn off the power to your projector and your Macintosh com-
puter.
2. Use the supplied signal cable to connect your Macintosh com-
puter to the projector.
3. Turn on the projector and the Macintosh computer.
Connecting Your Macintosh Computer
Macintosh (Desktop type)
Audio cable
(not supplied)
For older Macintosh,
use the supplied pin
adapter to connect to
your Mac's video
port.
Pin adapter for Macintosh
(supplied)
Signal cable
(supplied)
NOTE: The new Macintosh computer
such as G3 will have the 15 pin HD con-
nector. The VT440/VT540's "Plug and
Play" data will be downloaded to the
Macintosh. Therefore, the Mac adapter
will not be necessary.
Macintosh (Notebook type)
