Assert Error LED Operation
The panel LED operation display the line number of assert error occurrence.
Line number LED operation
start & end All LEDs(Toner low LEDs, Status(Red) LED, Black only LED) turn ON for approximately 2 sec-
onds and then All LEDs turn OFF for approximately 3 seconds.
1 After Status (Red) LED blinks one time, Toner low LEDs blink one time.
2 After Status (Red) LED blinks two times, Toner low LEDs blink one time.
3 After Status (Red) LED blinks three times, Toner low LEDs blink one time.
4 After Status (Red) LED blinks four times, Toner low LEDs blink one time.
5 After Status (Red) LED blinks five times, Toner low LEDs blink one time.
6 After Status (Red) LED blinks six times, Toner low LEDs blink one time.
7 After Status (Red) LED blinks seven times, Toner low LEDs blink one time.
8 After Status (Red) LED blinks eight times, Toner low LEDs blink one time.
9 After Status (Red) LED blinks nine times, Toner low LEDs blink one time.
