Alignment and Adjustmens
Samsung Electronics
Service Manual
6-15
6.6.3.3 LSU/ Fuser Test
Item Discription
LSU Motor If LSU motor lock signal is normal, "Successed" message will be displayed.
When LSU motor lock signal is abnormal , failed" message will be displayed.
When Upper Level is pushed, off message will be displayed.
LSU Power When select key is pushed, LSU Power On message will be displayed.
If not, LSU Power Off" message will be.
Laser Diode When select key is pushed, Laser Diode On message will be displayed.
If not, Laser Diode Off message will be.
PTL When select key is pushed, PTL On message will be displayed .
If not, PTL Off message will be.
Fuser When select key is pushed, Fuser On message will be displayed.
If not, Fuser Off message will be.
