User’s Manual 8-10
Optional Devices
3. Turn the computer upside down and remove the battery pack (refer to
Replacing the battery pack section in Chapter 6, Power, if required).
4. Loosen securing the memory module cover in place - please note that
this screw is attached to the cover in order to prevent it from being lost.
5. Slide your fingernail or a thin object under the cover and lift it off.
Figure 8-6 Removing the memory module cover
6. Align the notch of the memory module with that of the memory slot and
gently insert the module into the slot at about a 45 degree angle before
pressing it down until the latches on either side snap into place.
Memory module
cover
Screws
Slot B
Slot A
■ Align the grooves along the edges of the memory module with the
locking tabs on the connector and insert the module into the connector
firmly - if you find it difficult to install the memory module, gently prise
the locking tabs outwards using the tip of your finger.
Please also ensure that you hold the memory module along its left and
right hand edges - the edges with the grooves in.
