VXI Technology, Inc.
SM8000 Series Introduction 19
SM8003 PRISM SWITCH SPECIFICATIONS
GENERAL SPECIFICATIONS
WAVELENGTH RANGE
780 – 1570 nm
INSERTION LOSS
2
0.6 dB typical, 1.1 dB maximum
BACK REFLECTION
Single-Mode
Multi-Mode
- 55 dB maximum
-20 dB typical
CROSS-TALK
-80 dB maximum
DURABILITY
10 million cycles minimum
REPEATABILITY
2
±0.01 dB maximum
PDL
3
0.05 dB maximum
OPERATING TEMPERATURE
-20°C – 75°C
STORAGE TEMPERATURE
-40°C – 85°C
HUMIDITY
60°C / 90% Relative Humidity / 14 days
Notes
1 All specifications referenced without connectors.
2 Repeatability for 100 cycles at constant temperature.
3 Measured at 1550 nm, single-mode only.
