Switch Specifications
A-2 Specifications
Switch Specifications
Table A‐1providestheI/Oports,processorsandmemory,physical,andenvironmental
specificationsfortheA2H124‐24FX.
Table A-1 A2H124-24FX Switch Specifications
Item Specification
MT-RJ ports 1 through 24 Twenty-four 100BASE-FX compliant ports
RJ45 ports 25 and 26 Two 10/100/1000BASE-TX compliant ports with auto-sensing
and auto-negotiation via RJ45 UTP connectors for stacking. In
standalone mode, these ports can be used for host connections
and interswitch links.
SFP ports 27 and 28 Two slots that support optional Mini-GBICs 1000BASE-FX
fiber-optic connections and 1000BASE-T copper connections.
AC Input Specifications
Input Voltage 110 to 240 VAC
Input Current 1 A Max
Frequency 50 to 60 Hz
Processors/Memory
Processor MPC8241, 266 MHz processor with a 33 MHz PCI and 133 MHz
SDRAM
Dynamic Random Access
Memory (DRAM)
128 MB
FLASH Memory 16 MB
Physical
Dimensions 44.1 cm (17.36 in.) W x 4.4 cm (1.73 in.) H x 21.0 cm (8.27 in.) D
Approximate Weight Gross:
Net:
3.5 kg (7.68 lb) (shipping carton
containing one module)
2.7 kg (5.94 lb) (one module
without packaging)
Heat Dissipation (maximum) 174 BTU/HR
Predicted hours for Mean Time
Between Failures (MTBF)
53,501 hours
