3. Enter the required information
DDNS Active – If you want to use
DDNS, please set this field to
“Enabled” .
DDNS ISP Type – Select your
DDNS ISP Type.
Self-Define DDNS Address –
Self-define the DDNS server
instead of using DDNS ISP Type.
Site Name – The DDNS name for
your device.
DDNS Account/ DDNS Password – The account and password from the DDNS
Provider.
STUN Server – If the device is behind a router, a STUN server is needed to help
penetrate the NAT.
4. Click Save to save the changes. You might need to reboot the device to apply all the
changes.
GXV3615 Series SIP Page
The GXV3615 has the ability to receive phone calls and make phone calls when an alarm
event is triggered through motion detection or alarm input. Register the GXV3615 to a SIP
server to enable the product to make and receive phone calls. To make outgoing phone
calls out, the user needs to configure the Phone List properly.
Register GXV3615 to a SIP Server
1. From the GXV3615 home page, click Basic Settings > SIP.
2. Go to SIP Settings Tab.
3. General Phone Settings.
Registered – The field shows the registration
status of the account with the SIP server.
Unregister On Reboot – If it‟s checked, the SIP user‟s registration information will be
cleared from the server when the phone reboots.
4. Enter the required information.
Account Name – The field configures the SIP account name.
SIP Server – The SIP Server‟s IP address or Domain name provided by your service
provider.
Outbound Proxy – The IP address or Domain name of the Outbound Proxy, Media
Gateway, or Session Border Controller. Used for firewall or NAT penetration in different
network environments. If the system detects a symmetric NAT, STUN will not work.
ONLY outbound proxies can provide a solution for a symmetric NAT.
