GXV3615 IP Camera Series
Firmware 1.0.4.8 Page 21 of 28
Grandstream Networks, Inc. 11 /29/10
Firmware Upgrade and Provisioning Items
Upgrade via – This field lets you
choose the firmware upgrade
method. The GXV3615 supports
HTTP, HTTPS and TFTP.
Firmware Server Path – The IP
address or domain name of the
firmware server (the location of the
firmware files) .
Automatic Upgrade Interval – Enter the frequency (in minutes) in which the
HTTP/HTTPS/TFTP server will be checked for new firmware upgrades or configuration
changes.
Automatic Upgrade – The default setting is “No.” Choose “Yes” to enable automatic.
HTTP/HTTPS/TFTP upgrade and provisioning. When set to “ No”, the IP Camera will only
perform a HTTP/HTTPS/TFTP upgrade and perform a configuration check once during the
boot process.
Performing a firmware upgrade:
1. Download the firmware package from http://www.grandstream.com/firmware.html.
2. Unzip the firmware package and copy the files to the firmware upgrade server
directory.
Upgrades are supported via TFTP, HTTP and HTTPS.
3. Log in to the Maintenance page of the GXV3615. Select the server type from the
dropdown list under the “Upgrade Via” field. Enter your server‟s root directory in the
“Firmware Server Path” field.
4. Reboot the GXV3615 to begin the firmware upgrade process.
GXV3615 Series SMTP Page
The SMTP server is used to send out emails when
an alarm event or motion detection is triggered.
The SMTP settings must be configured to make sure
the alarm email is sent out properly.
SMTP Server Settings
Enable SMTP – Checked to enable SMTP
SMTP Server – The IP or hostname of the SMTP
server, for example, smtp.gmail.com.
SMTP Server Port – The port of the SMTP server.
The GXV3615 supports port 25 and SSL port 465,
