Setup Motion Detection Monitored Area
Enable Motion Detection – If this option is selected, motion detection will be enabled. If
something/somebody moves in the motion detection region, an alarm will be triggered.
Show Motion Detection Regions – If
this option is selected, the motion
detection regions will be displayed on
the screen with a white border.
To Edit a Monitored Area
1. In the Select a Region dropdown list, select
the region ID.
2. Click Edit.
3. Click on the video, drag and draw you
preferred area.
4. Set the Sensitivity. Click the Save button to
save the sensitivity.
NOTE: The Sensitivity value varies from 0 to
100. The larger the value is, the higher the
sensitivity.
5. Click Save to save the settings.
To Remove a Monitored Area
1. In the Select a Region dropdown list, select the region you would like to remove.
2. Click Remove.
3. Click Save to save the changes.
Configure Motion Detection & Alarm Actions
An alarm action is what the GXV3615 is going to do
when an alarm is triggered during the defined time
period – the time schedule. The GXV3615 allows
Button to save sensitivity only
The white border for Motion
Detection Regions
NOTE: If Upload to Alarm center
is checked for Alarm Actions, the
white border will flash red when a
motion detection alarm is triggered.
