Adjusting Paper Path Alignment
6-22 Advanced Topics
6. Select tray1 and press
Ǡ. This is the Maintenance.alignment screen, shown in
Figure 6-16.
Figure 6-16 Maintenance.alignment Tray1 setting
7. Press either į or Ĭ to highlight the tray1 new value calculated on the Simplex feed
alignment ruler sheet. The selection range is from -25 to +25, (except for duplex
lengthwise, which is +7 to -7). See Figure 6-17.
Figure 6-17 Tray1 values
8. Press Select to save the new value and to return to the Maintenance.alignment submenu.
9. Repeat steps 1 through 4 for trays 2, 3, HCI, duplex (duplex sideways), and duplexv
(duplex lengthwise).
10. Verify your alignment by repeating the procedure in “Printing Alignment Sheets” on
page 6-12. If the alignment is still off (plus or minus 3 to 4 increments or more), note
the adjustment values as you did in the previous alignment procedure, and set the new
adjustment values in the Control Panel.
Note A 1 or 2 increment variation may remain after alignment; this is normal.
Online
Maintenance.alignment
Online
tray1
tray2
tray3
duplex
duplexv
= 5
= 6
= 5
= -6
= -7
Online
Maintenance.alignment.tray1 =
Online Select
5
6
7
8
9
10
