Chapter 1 15
System Memory
Hard Disk Drive Interface
Features • Support PCI bus at 33MHz
• Supports four SATA ports, complying with the SATA 1.0a
specification
• 5 OHCI and 1 EHCI Host controllers to support 10 USB ports,
• audio
• 4 Independent output stream(DMA).
• 4 Independent input stream(DMA).
• Up to 16 channels of audio output per stream.
• Support up to 4 Codecs.
• Up to 192Khz sample.
• IDE Controller
• Single PATA Channel support.
• Supports PIO, Multi-word DMA, and Ultra DMA 33/66/100/
133.
• AC Link Interface
• Support for both audio and modem Codecs.
• 6/8 channel support on audio codec.
• Power +3V,+1.2V, +3V_S5, +1.2V_S5, +1.8V, VCC_SB
•TDP:4W
Item Specification
Memory size Up to 2GB
DIMM socket number 1
Supports memory size per socket 2GB
Supports maximum memory size 2GB
Supports DIMM type DDR2
Supports DIMM Speed 667MHz
Item Specification
Vendor &
Model Name
Hitachi
HTS543216L9
SA00
Hitachi
HTS545016B9
A300
Hitachi
HTS545025B9
A300
Seagate
ST9160310AS
Seagate
ST9160315AS
Capacity (GB) 160 160 250 160 250
Bytes per
sector
512 512 512 512 512
Data heads 22222
Drive Format
Disks11211
Spindle speed
(RPM)
5400 5400 5400 5400 5400
Performance Specifications
Buffer size 8 MB 8 MB 8 MB 8 MB 8 MB
Interface SATA SATA SATA SATA SATA
Fast data
transfer rate
(Mbits/sec,
max)
1500 3000 3000 3000 3000
Item Specification
