42 Chapter 3 AirPort Network Designs
Setting Up Roaming
Several AirPort Extreme Base Stations or Time Capsules can be set up to create a single
wireless network. Client computers using AirPort can move from device to device with
no interruption in service (a process known as roaming).
To set up roaming:
1 Connect all of the AirPort Extreme Base Stations and Time Capsules to the same subnet
on your Ethernet network.
2 Give each device a unique name.
3 Give each device the same network name and password.
4 Set up the devices as bridges, following the instructions in the previous section.
If you want one device to assign IP addresses using DHCP, also do the following:
1 Set up one device to act as the DHCP server.
2 Set up the other devices as bridges, following the instructions in the previous section.
The device acting as a DHCP server can also receive its IP address via DHCP from a
server on an Ethernet network or from a cable or DSL modem connected to an Internet
service provider (ISP).
to Ethernet port
to Internet
Ethernet LAN ports
AirPort Extreme
DSL or cable modem
G
Time Capsule
Ethernet WAN port
<
2.4 or 5 GHz
2.4 GHz
