4-18 Chapter 4: BIOS setup
4.4 Advanced menu
The Advanced menu items allow you to change the settings for system devices.
Phoenix-AwardBIOS CMOS Setup Utility
Main Advanced Power Boot Tools Exit
Select Menu
Item Specic Help
Adjust system
frequency/voltage.
JumperFree Conguration
AI NET 2
CPU Conguration
Chipset
PCIPnP
Onboard Device Conguration
USB Conguration
F1:Help : Select Item -/+: Change Value F5: Setup Defaults
ESC: Exit : Select Menu Enter: Select SubMenu F10: Save and Exit
Take caution when changing the settings of the Advanced menu items. Incorrect
AI Tuning [Auto]
Allows selection of CPU overclocking options to achieve desired CPU internal
Manual Allows you to individually set overclocking parameters.
Auto Loads the optimal settings for the system.
Standard Loads the standard settings for the system.
AI Overclock
stability when overclocking.
Select Menu
Item Specic Help
Press [Enter] to
select overclock
prole
JumperFree Conguration
AI Tuning [Auto]
x Overclocking Options Disabled
CPU Voltage [Auto]
VDDA Voltage [Auto]
Memory Voltage [Auto]
NB BR04 CHIP Voltage [Auto]
1.2V HT Voltage [Auto]
NB CHIP Voltage [Auto]
x CPU Multiplier Auto
x CPU Frequency 200
Phoenix-Award BIOS CMOS Setup Utility
Advanced
4.4.1 JumperFree Conguration
