AXIS 250S User’s Manual Installing the AXIS 250S
13
Accessing the AXIS 250S from Internet Explorer
Important!
Configuring the video source and audio equipment
You should now configure the connected video source and audio equipment:
1. From the administration tools, open the Video settings page.
2. Select the physical connector the camera or other equipment is connected to.
3. Set the Source modulation to the correct type for your camera. NTSC is the standard in
the United States and PAL is the standard used in Europe. If unsure, check the
documentation supplied with the camera.
4. Open the Audio settings page.
5. Select the audio input you connected your equipment to.
6. Enable audio, set the desired audio quality, and set the Mic Input Sensitivity according
to your microphone. Click Save and then return to the Live View page to view the
video stream.
See also the configuration section for audio and video on page 22.
Upon delivery, the AXIS 250S is supplied with one pre-configured Administrator user name and pass-
word, set to root and pass, respectively. The Administrator password should be changed as soon as pos-
sible, to prevent unauthorized access to the setup tools and/or the video stream.
❶ Start your browser and enter the IP address of the AXIS
250S in the location/address field. The first time the server is
accessed, there will be no need to log in.
❷ The main application page now opens,
allowing you proceed with the product’s
configuration by clicking on the Setup
link.
