Operating the AXIS 250S AXIS 250S User’s Manual
16
Disconnected Video Source
Any problem with the camera or video source is indicated by a blank display. This may
indicate a break in the signal transmission or the cable, and any such incident should be
immediately referred to your system administrator.
Positional Control of the Video Source
Video cameras supporting Pan Tilt and Zoom (PTZ) are connected and controlled directly
from the server’s ports.
A PTZ-configured video source is automatically displayed with Pan, Tilt and Zoom bars, as
shown in the illustration below:
Notes: •The AXIS 250S can control a range of relative and absolute PTZ devices via the Web interface, or
via a third-party application. The positioning tools provided depend on the selected PTZ device.
Other functions, not shown in the illustration, may also be available.
•PTZ controls can be disabled in the Live View layout settings and may be unavailable in the user
interface.
•Clicking anywhere on a toolbar’s gradient allows for a “smooth” PTZ adjustment; whereas click-
ing on the left or right arrows causes a stepped incremental change.
Pan
Allows smooth or stepped hori-
zontal panning of the camera.
Zoom
Allows smooth or stepped camera zoom
between telescopic and wide viewing.
Tilt
Allows smooth or
stepped vertical pan-
ning of the camera.
Home (H)
Returns the camera
to the ‘Home’ position.
Select Preset Position
To enable quick and accurate camera
positioning, up to 20 preset camera
positions can be set and selected at
any time from the drop-down dialog.
