Technical Specifications AXIS 250S User’s Manual
52
Approvals - EMC
• EN 55022:1998 (CISPR 22:1997), Class B - Emission, Europe.
• EN 55024:1998 - Immunity, Europe. (Line input only. The Mic input may be subject to interfer-
ence from nearby radio transmitters.)
• EN 61000-3-2:1995+A1+A2+Corrig.+A14 - Power, Harmonic current emission.
• EN 61000-3-3:1995+A1 - Power, Flicker and inrush current.
• EN 61000-6-2:1999
• FCC part 15, Subpart B, Class B demonstrated by compliance with EN 55022 (CISPR 22)
• VCCI Regulations 2001 - Japan.
• C-Tick AS/NZS 3548 - Australia.
Approvals - Safety - EN60950, CSA.
Metrics: - Height: 1.1” (27mm), Width: 4.4” (112mm), Length: 5,2” (133mm), Weight:
1.52lb (0.69kg) excluding Power Supply.
Hardware - MPEG-2 compression chip, ETRAX-100LX, 32-bit RISC, 100 MIPS CPU, 16 MB
RAM, 4 MB FLASH PROM.
Power - PS-K, (included) 9V DC, 9W. Alternative supply 7-20V DC, min 7W.
Complimentary Software - AXIS MPEG-2 Viewer (Axis ActiveX component software for
Microsoft Internet Explorer - supplied with the product). AXIS IP Installer - for quick
installation of multiple units - available from the Axis web site.
File size - The file sizes delivered by the AXIS 250S can be calculated as follows:
All specifications are subject to change without prior notice.
(Ba + Bv) x 1000 x 60
8
= file size in bytes/minute
Bv = Bit rate for video (kbit/s), Ba = Bit rate for audio (kbit/s, 0 if not enabled).
