1-5 1-5user's manual R5975236-r3 user's manual R5975236-r3
Baud rate table
BD5000, BD5000LC, BD8000
S1:4 S1:3 S1:2 S1:1 Baud rate (baud)
off off off off 5 0
off off off o n 7 5
off off o n off 1 00
off off o n o n 110
off o n off off 1 50
off o n off o n 200
off o n o n off 300
off on on on 600
on off off off 1200
on off off on 2400
on off on off 4800
on off on on 9600
on on off off 19200
on on off on 9600
on on on off 9600
on on on on 9600
Baud rate table
BD3000, BD3000LC, BD3100, BD3100LC, BD5100,
BD5100LC, BD8100, BD8100LC
S2:3 S2:2 S2:1 Baud rate (baud)
off off off 9600
off off on 4800
off on off 2400
off on on 1200
o n off off 600
on off on 300
on on off 150
on on on 75
Baud rate table
BD5000, BD5000LC, BD8000
S1:4 S1:3 S1:2 S1:1 Baud rate (baud)
off off off off 5 0
off off off o n 7 5
off off o n off 100
off off o n o n 1 10
off o n off off 150
off o n off o n 2 00
off o n o n off 3 00
off on on on 600
on off off off 1200
on off off on 2400
on off on off 4800
on off on on 9600
on on off off 19200
on on off on 9600
on on on off 9600
on on on on 9600
Baud rate table
BD3000, BD3000LC, BD3100, BD3100LC, BD5100,
BD5100LC, BD8100, BD8100LC
S2:3 S2:2 S2:1 Baud rate (baud)
off off off 9600
off off on 4800
off on off 2400
off on on 1200
o n off off 6 00
on off on 300
on on off 150
on on on 75
communication settings
Chapter 1: Communications basics
Chapter 1: Communications basics
communication settings
