1-6 1-6user's manual R5975236-r3 user's manual R5975236-r3
Connector labelled RS232 IN
This female D9-pin connector is used to connect the projector with the
computer.
Connector labelled RS232 OUT
This male D9-pin connector is used to drive the next projector in a chain.
Pin-out
The pin-out is the standard PC-AT convention, which is :
Pin # Name Full name
1 CD Carrier Detect
2 RxD Received Data
3 TxD Transmitted Data
4 DTR Data Terminal Ready
5 GND Signal Ground
6 DSR Data Set Ready
7 RTS Request To Send
8 CTS Clear To Send
9 RI Ring Indicator
Connector labelled RS232 IN
This female D9-pin connector is used to connect the projector with the
computer.
Connector labelled RS232 OUT
This male D9-pin connector is used to drive the next projector in a chain.
Pin-out
The pin-out is the standard PC-AT convention, which is :
Pin # Name Full name
1 CD Carrier Detect
2 RxD Received Data
3 TxD Transmitted Data
4 DTR Data Terminal Ready
5 GND Signal Ground
6 DSR Data Set Ready
7 RTS Request To Send
8 CTS Clear To Send
9 RI Ring Indicator
Chapter 1: Communications basics Chapter 1: Communications basics
hardware hardware
