WATLOW Series 945
How to Use Data Communications
Index
A
ALM, 20
ANSI X3.28 "=" Command, Fig. 8, 17
ANSI X3.28 "?" Command, Fig. 9, 18
ANSI X3.28 Protocol for RS-422A & EIA-485, 3, 16
ASCII Character Set, Table 1, 10
ASCII Control Characters (Partial Set), Table 2, 10
AXHI, 20
AXLO, 20
ATMN, 20
AUT, 20
B
Baud Rate, 8
BTYP, 19
C
C1, 19
CAL, 20
Carriage Return, 13
CF, 20
Chart Printout, 25
CLUP, 9, 20
Command, "?", 19
Command, "=", 20
Command Data & Responses, Partial Set for "?", 19
Command Data "=" and "?", Table 6, 20
Command List, 12
Communications
Parameters, 8
Switch Selection, 7
Wiring, 3
Connecting the Control and the Computer, 7
CTX, 20
D
Data Parameters, 8
Data Link Escape (DLE), 17
Data Logging, 22
Data Rules, 11
DB, 20
DEC, 20
Device Address, 16
E
EIA-485, 3, 6
End of Text (ETX), 13
End of Transmission (EOT), 17
ERR, 19
ER2, 19
Example Format, 12
F
Flow Control, 13
G
General Message Syntax, 11
H
How to Use Data Comms. with the Series 945, 3
HYSX, 20
I
Identification Number, 16
IN, 19
INDC, 20
INT, 20
Interface Wiring,
RS-422A, Fig. 1, 4
RS-423A, Fig. 2, 5
EIA-485, Fig. 3, 6
L
LATX, 21
LOC, 21
LOG, 8, 21, 22
L-R, 21
LSL, 21
M
MAN, 21
MDL, 19
Message Syntax, 11
MODE, 19
Multidrop, 3
N
NAKs and Error Codes, 26
Network connections, 7
O
OT
X, 21
P
PB
X, 21
Protocol,
XON-XOFF, 13
ANSI X3.28, 16
R
RA
X, 21
REX, 21
RS-422A, 3, 4
RS-423A, 3, 5
RSP, 19, 21
RH, 21
RL, 21
S
Setup Menu, 8
SPC, 23
SP
X, 21
Space, 12
Starting Communications in ANSI X3.28 Protocol, 16
Start of Text (STX), 13
Stopping Communications in ANSI X3.28 Protocol, 17
T
Table Printout, 23
TAG, 21
tbS, 20
Two Hardware Interfaces & Protocols, 3
U
USL, 21
W
Wiring Data Communications, 4 - 6
X
XON/XOFF
"=" Command Example, Fig. 6, 14
"?" Command Example, Fig. 7, 15
