Printer Operation
32
Menu Setting Table
Global Config menu - allows you to switch between 3 complete ‘config sets’ contained within the printer.
Page Setup Menu - allows you to change settings related to the media or print quality.
System Setup Menu - allows you to change settings for the printer hardware and basic control systems.
After Print Menu - changes how the printer reacts after the label has been printed.
Interfaces - changes interface parameters such as baud rate.
Menu Setting
7 Datamax
®
Emulation
Mode Settings
[Datamax
®
Emulation]
Top Menu Sub Menu Default Menu Remarks
Global – Config Set 1 Config Set 1 Sets the Config Set.
configuration Config Set 2
Config Set 3
Page Setup Print Speed 4 IPS 2 to 6 IPS Printing speed setting
(2 to 4 IPS with optional peeler.)
Print Darkness 10 00 to 30 Print darkness setting
(printhead temperature)
Darkness Adjust 0 -10 to 10 Darkness command adjustment
Continuous Media 4.00 IN 0.25 to 32.00 IN Setting default length of continuous media,
Length 101.6mm 6.40 to 812.8mm if selected. ; the lower line is in metric mode.
Vertical Position 0.00 IN -1.00 to 1.00 IN Print start position adjustment
0.0mm -25.4 to 25.4mm
Horizontal Shift 0.00 IN -1.00 to 1.00 IN Horizontal printing location adjustment
0.0mm -25.4 to 25.4mm
Vertical Image Shift 0.00 IN 0.00 to 32.00 IN Adjust the off set value in vertical when
0.0mm 0.0 to 812.8mm mapping data on a RAM.
Media Sensor See Through See Through Label sensor selection
Reflect
None
Small Media OFF ON Setting for small labels
Adjustment OFF
Small Media 1.00 IN 0.25 to 1.00 IN Setting length of small label media
Length 25.4mm 6.40 to 25.4mm
System Setup Sensor Level 1.5V 0.0V to 3.3V Setting the threshold of the sensor
Paper End Level 2.80V 0.01V to 3.00V Sets the paper end level.
Error Reporting On Printing On Printing Setting for error report.
Immediate
Buzzer Select ON ON Setting buzzer sounding conditions
OFF
Metric/Inch Inch Inch Setting the units used
mm
Max Media Length 10.00 IN 1.00 to 50.00 IN Setting the maximum label length
254.0mm 25.4 to 1270.0mm
Settings Lock Off On When on, prevents software commands from
Off changing the values set by the VuePrint menu
Keyboard Lock Off On Prevents the control panel from affecting the
Off printer's configuration. (User "lock-out")
Control Code STD STD Selects between the Standard STX control
ALT code or the "Alternative" code. Sometimes
ALT-2 called "AS400 mode".
