35
Printer Operation
7 Zebra
®
Emulation
Top Menu Sub Menu Default Menu Remarks
Global – Config Set 1 Config Set 1 Sets the Config Set.
configuration Config Set 2
Config Set 3
Page Setup Print Speed 4 IPS 2 to 6 IPS Printing speed setting
(2 to 4 IPS with optional peeler.)
Print Darkness 10 00 to 30 Print darkness setting
(printhead temperature)
Darkness Adjust 0 -10 to 10 Darkness command adjustment
Continuous Media 4.00 IN 0.25 to 32.00 IN Setting default length of continuous media,
Length 101.6mm 6.40 to 812.8mm if selected. ; the lower line is in metric mode.
Vertical Position 0.00 IN -1.00 to 1.00 IN Print start position adjustment
0.0mm -25.4 to 25.4mm
Horizontal Shift 0.00 IN -1.00 to 1.00 IN Horizontal printing location adjustment
0.0mm -25.4 to 25.4mm
Vertical Image Shift 000dots -120 to 120 dots Adjust the off set value in vertical when
mapping data on a RAM.
Media Sensor See Through See Through Label sensor selection
Reflect
None
Small Media OFF ON Setting for small labels
Adjustment OFF
Small Media 1.00 IN 0.25 to 1.00 IN Setting length of small label media
Length 25.4mm 6.40 to 25.4mm
System Setup Sensor Level 1.5V 0.0V to 3.3V Setting the threshold of the sensor
Paper End Level 2.80V 0.01V to 3.00V Sets the paper end level.
Error Reporting On Printing On Printing Setting for error report.
Immediate
Buzzer Select ON ON Setting buzzer sounding conditions
OFF
Metric/Inch Inch Inch Setting the units used
mm
Max Media Length 10.00 IN 1.00 to 50.00 IN Setting the maximum label length
254.0mm 25.4 to 1270.0mm
Settings Lock Off On When on, prevents software commands from
Off changing the values set by the VuePrint menu
Keyboard Lock Off On Prevents the control panel from affecting the
Off printer's configuration. (User "lock-out")
Media Power Up Off On Selects whether or not to initiate media
Off measurement when the power in ON.
CI Lock Off On Activates/deactivates the CI command.
Off
Emulation Select ZPI2 DM4 Selects DataMax
®
/Zebra
®
compatibility
DMI DM4: DataMax
®
400
DPP DMI: DataMax
®
IClass
ZPI2 DPP: DataMax
®
Prodigy Plus
®
ZPI2: Zebra
®
Emulation
Emulation Auto On On Selects the detection of Datamax
®
and
Detect Off Zebra
®
emulation.
Full Auto
Mode Settings
[Zebra
®
Emulation]
