47
Appendixes
Specifications
Item Description
Printing Printing method Direct thermal
Resolution Main scanning line density: 203 dots/inch (8 dots/mm)
Sub- scanning line density: 203 dots/inch (8 dots/mm)
Head 864 dots (effective dots: 832 dots)
Max. print width 104 mm 4.1 inch
Max. print length 812.8 mm 32 inch
Print density Print density is adjustable with software
Printing speed Printing speed setting 6, 5, 4, 3 or 2 inches per second.
• 2-4 inches per second with optional peeler.
Print mode Batch mode Normal printing (single or multiple sheets)
Tear off mode Feeds back media to the tear-off position after printing is completed.
Cut mode
*1
Prints while cutting at designated sheet units.
The following two kinds of cut mode operations are done.
• Backfeed
• Cut through
(Cut through refers to stopping present printing to cut the previous label
when it reaches the cut position. After cutting, printing restarts but a gap
may be created at the seam of the printing at this time.)
Peel mode
*1
Peels labels from the liners after printing them.
Media Types of media Roll, fanfold
(continuous media, die-cuts, continuous tags. paper or tickets)
Kinds of media Thermal-transfer media
Recommended media Heat-transfer media: label media (150LA-1 Ricoh),
tag media (TB2E0V, Mitsubishi Paper)
Max. media width 118.0 mm 4.65 inch
Min. media width 19.5 mm 0.77 inch
Min. label width 19.5 mm 0.77 inch
Min. label pitch
*2
6.35 mm 0.25 inch
Max. media thickness 0.254 mm 0.01 inch
Max. media length 812.8 mm 32 inch
Min. media length 6.35 mm 0.25 inch
Min. media thickness 0.0635 mm 0.0025 inch
On-board roll media Max. external diameter: 127mm 5 inch
diameter
Media core: 25.4 to 76mm 1 to 3 inch
Bar code One-dimension • Code 3 of 9 • UPC-A • UPC-E • EAN-13 (JAN-13)
(for Datamax
®
emulation) • EAN-8 (JAN-8) • Interleaved 2 of 5 • Code 128
• HIBC (Modulus 43-used code 3 of 9) • Codabar (NW-7)
• Int 2 of 5 (Modulus10-used Interleaved 2 of 5) • Plessey
• Case Code • UPC 2DIG ADD • UPC 5DIG ADD
• Code 93 • Telepen • ZIP • UCC/EAN128
• UCC/EAN128 (for K-MART)
• UCC/EAN128 Random Weight • FIM
Two-dimension • UPS Maxi Code • PDF-417 • Data Matrix • QR Code • Aztec
• RSS
