1-3
1-3 Types
• @E.Terminal for MC
Product types Display size Specifications
NP5M0101-5H4 12.1 inches
TFT color, 800 x 600 dots, DC power supply
Controller unit
Contents of the motion control
(Screen data, built in software in the controller)
NP5M0101-4H4 10.4 inches
NP5M0101-3H4 8.4 inches
• @E.Terminal (No contents installed)
Product types Display size Specifications
NP5N0011-5H4 12.1 inches
TFT color, 800 x 600 dots, DC power supply
Controller unit
No contents installed
NP5N0011-4H4 10.4 inches
NP5N0011-3H4 8.4 inches
• Accessories
Product types Names Quantity
NP5M0101-5H4
NP5M0101-4H4
NP5M0101-3H4
NP5N0011-5H4
NP5N0011-4H4
NP5N0011-3H4
Instruction Manual 1
Backup CD of the @E.Terminal for MC Note1) 1
SX bus terminating plug 2
Screw driver 1
Fixture 4
Binder for USB cable (Only NP5M0101-3H4/NP5N0011-3H4) 1
USB cable cramp for port A/B (Only NP5M0101-5H4/4H4, NP5N0011-5H4/4H4) 2
M3 x 8 screw for USB cable cramp (Only NP5M0101-5H4/4H4, NP5N0011-5H4/4H4) 2
Noise filter Note2) 1
Note 1: Backup CD is not attached to NP5N0011-5H4/4H4/3H4.
Note 2: Noise filter is not attached from controller unit hardware version 03 or later.
• Screen drawing tools
Names Types Specifications
Configuration software:
English version
V-SFT-5 Screen editor:
Windows98SE/NT4.0/Me/2000/XP/XP64Edition/Vista32-bit
compatible
Screen data transfer cable V-CP 3m, Used for connection between the V8 series and a personal
computer.
• Programming support tool for controller
Names Types Specifications
SX-Programmer Standard NP4H-SWN Programming support tool SX-Programmer Standard,
Standard expansion FB, Windows95/98/ME/2000/XP/NT4.0
SX-Programmer Expert
(D300win)
NP4H-SEDBV3 IEC61131-3 based on Programming support tool D300winV3,
Standard expansion FB, Windows2000/XP/NT4.0
Support tool cable NW0H-CNV RS-232C/RS-485 converter for the programming support tool for AT
compatible personal computer
NW0H-CA3 Support tool connection cable (Used to combined the NW0H-CNV)
