2-8
2-2 Dimensions and Panel Cut-out
Note: Arrange SX bus expansion cable so that
radius of bend in the cable is at least 50mm.
Plug/unplug the SX bus expansion cable in
the perpendicular direction.
2-2-1 External dimensions and panel cut-out dimensions for the NP5M0101-5H4/NP5N0011-5H4
(Unit: mm)
CN5
313.0
+0.5
-0
246.2
+0.5
-0
326.4
259.6
99.0
(66)
7.0
312.0
245.2
312.0
99.0
F 7F 6F 5F 4F 3
F 2
F 1
SYSTEM
4:RUN
3:U-TERM
2:TERM
1:STOP
ONL
ERR
UROM
RUN
ALM
BAT
No.
CPU
SX-BUS
IN
USB
LOADER
USER ROM CARD
OUT
U-B U-A
LAN
CN1
MJ2
MJ1
CN7
CF
• Front view
• Rear view
• Side view
Panel cut-out dimensions
• Bottom view
Note)
24V DC
+
-
FG
