3-24 Section 3: Installation
February 3, 2000 70055MP Revision D
Once power is applied, and configuration parameters have been uploaded
to the monitor, the monitor enters normal operation and begins monitoring
sensor and voltage inputs.
Refer to Section 4 - Operation for further operation procedures.
Calibrate Tap Position
1. Press the Setup button to display the Tap Position Input Calibration
Low Point screen.
T A P P O S I T I O N
I N
P U T
C A L I B R A T I O N
L O W
P O I N
T :
â
5
á
The Setup button is located on the upper left corner of back side the
CPU board.
2. Observe and record the actual tap position of the LTC at the TAP
Position Indicator.
3. Adjust the value of the low tap position calibration point to the value
observed in Step 2 by pressing â or á until the correct value is
displayed
4. Press Setup to display the Tap Position High Point Calibration screen.
T A P P O S I T I O N
I N
P U T
C A L I B R A T I O N
H I G H P O I N
T :
â
6
á
5. Manually move the tap up one position.
6. Adjust the value of the high tap position calibration point up one
position from the low calibration point by pressing â or á until the
correct value is displayed.
7. Press Setup to exit the Calibration and return to normal operation.
