CONFIGURATION GUIDE
The GXP2020 can be configured in two ways. Firstly, using the Key Pad Configuration Menu on the phone;
secondly, through embedded web-configuration menu.
C
ONFIGURATION WITH KEY PAD
To enter the MENU, press the round button. Navigate the menu by using the arrow keys: up/down and
left/right. Press the OK button to confirm a menu selection, delete an entry by pressing the MUTE/DEL button.
The phone automatically exits MENU mode with an incoming call, the phone is off-hook or the MENU mode if
left idle for 20 seconds.
Press the MENU button to enter the key the Key Pad Menu. The menu options available are listed in table 8.
Table 9: Key Pad Configuration Menu
Call History Displays histories of incoming, dialed and missed calls.
Status
Displays the network status, account statuses, software version and
MAC-address of the phone.
Phone Book Displays the phonebook
Instant Messages Goes to voice messages
Direct IP call Displays the IP-call options menu
Preference
Displays preference menu. Here ring tones, ring volume and XML screen
settings can be modified
Config
Display configuration menu. Here network, SIP and audio settings can be
modified. The FACTORY RESET function is stored here too.
Factory Functions
Extra diagnostic tools reside here.
Reboot
Makes the phone reboot itself.
Exit Exit from this menu.
Display “Preference” Press Menu button to enter this sub menu including
• “Do NOT Disturb”
DND (Do NOT Disturb) function could be turned on or off in
the “DO NOT Disturb” menu.
• Ring Tone
Choose different ring tones in the “Ring Tone” menu.
• Ring Volume
Press Menu button to hear the selected ring volume, press
‘←’ or ’ →’ to hear and adjust the ring tone volume.
• Download SCR XML
The phone will download the custom idle screen (if available)
• Erase Custom SCR
Custom idle screen will be erased and will be replaced with
default Grandstream logo.
Press Menu button to choose the menu item.
Press ‘←’ to return to the main menu.
Grandstream Networks, Inc. GXP–2020 User Manual Page 19 of 32
Firmware 1.1.4.3 Last Updated: 06/2007
