Advanced User configuration includes not only the end user configuration, but also advanced
configuration such as SIP configuration, Codec selection, NAT Traversal Setting and other miscellaneous
configuration.
Table 12: Advanced User Configuration Page Definitions
Admin
Password
Administrator password. Only the administrator can configure the “Advanced Settings”
page. Password field is purposely blank for security reasons after clicking update and
saved. The maximum password length is 25 characters.
Silence
Suppression
This controls the silence suppression/VAD feature of the audio codec G.723 and G.729.
If set to “Yes”, when silence is detected, a small quantity of VAD packets (instead of
audio packets) will be sent during the period of no talking. If set to “No”, this feature is
disabled.
Voice Frames
per TX
This field contains the number of voice frames to be transmitted in a single Ethernet
packet (be advised the IS limit is based on the maximum size of Ethernet packet is 1500
byte (or 120kbps)).
When setting this value, be aware of the requested packet time (ptime, used in SDP
message) is a result of configuring this parameter. This parameter is associated with the
first codec in the above codec Preference List or the actual used payload type
negotiated between the 2 conversation parties at run time. e.g., if the first codec is
configured as G.723 and the “Voice Frames per TX” is set to 2, then the “ptime” value in
the SDP message of an INVITE request will be 60ms because each G.723 voice frame
contains 30ms of audio. Similarly, if this field is set to 2 and the first codec is G.729 or
G.711 or G.726, then the “ptime” value in the SDP message of an INVITE request will be
20ms.
If the configured voice frames per TX exceeds the maximum allowed value, the IP phone
will use and save the maximum allowed value for the corresponding first codec choice.
The maximum value for PCM is 10 (x10ms) frames; for G.726, it is 20 (x10ms) frames;
for G.723, it is 32 (x30ms) frames; for G.729/G.728, 64 (x10ms) and 64 (x2.5ms) frames
respectively.
Please be careful when editing these parameters. Adjusting these parameters will also
change the dynamic jitter buffer. The GXP2020 has a patent dynamic jitter buffer
handling algorithm. The jitter buffer range is 20 ~ 200 ms.
Grandstream recommends using the default settings provided. Grandstream does not
recommend adjusting these parameters if you are an average user. Incorrect settings
will affect the voice quality. Please refer to the Codec FAQ at
http://www.grandstream.com/FAQ/FAQ-Codec.pdf for more technical detail.
Layer 3 QoS
This field defines the layer 3 QoS parameter. It is the value used for IP Precedence or
Diff-Serv or MPLS. Default value is 48.
Layer 2 QoS
This contains the value used for layer 2 VLAN tag. Default setting is blank.
No Key Entry
Timeout
Default is 4 seconds.
Grandstream Networks, Inc. GXP–2020 User Manual Page 24 of 32
Firmware 1.1.4.3 Last Updated: 06/2007
