Memory module
Description Spare part number
2-GB memory module (PC3L-12800, 1600-MHz, DDR3) 691739-005
4-GB memory module (PC3L-12800, 1600-MHz, DDR3) 691740-005
8-GB memory module (PC3L-12800, 1600-MHz, DDR3) 693374-005
Before removing the memory module, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet, and
then unplugging the AC adapter from the computer.
4. Disconnect the tablet from the keyboard dock (see
Releasing the tablet from the keyboard dock
on page 32).
5. Remove the display rear cover (see
Display rear cover on page 45).
6. Disconnect the battery cable (see
Battery cable on page 46).
Remove the memory module:
1. Spread the retaining tabs (1) on each side of the memory module slot to release the memory module.
(The edge of the module opposite the slot rises away from the computer.)
2. Remove the memory module (2) by pulling the module away from the slot at an angle.
NOTE: Memory modules are designed with a notch to prevent incorrect insertion into the memory
module slot.
Reverse this procedure to install a memory module.
Tablet components 47
