Intel® Xeon® Processor E5-1600/E5-2600/E5-4600 Product Families 25
Datasheet Volume One
Interfaces
2 Interfaces
This chapter describes the interfaces supported by the processor.
2.1 System Memory Interface
2.1.1 System Memory Technology Support
The Integrated Memory Controller (IMC) supports DDR3 protocols with four
independent 64-bit memory channels with 8 bits of ECC for each channel (total of
72-bits) and supports 1 to 3 DIMMs per channel depending on the type of memory
installed. The type of memory supported by the processor is dependent on the target
platform:
• Intel® Xeon® processor E5 product family-based platforms support:
— ECC registered DIMMs: with a maximum of three DIMMs per channel allowing
up to eight device ranks per channel.
— ECC and non-ECC unbuffered DIMMs: with a maximum of two DIMMs per
channel thus allowing up to four device ranks per channel. Support for mixed
non-ECC with ECC un-buffered DIMM configurations.
2.1.2 System Memory Timing Support
The IMC supports the following DDR3 Speed Bin, CAS Write Latency (CWL), and
command signal mode timings on the main memory interface:
• tCL = CAS Latency
• tRCD = Activate Command to READ or WRITE Command delay
• tRP = PRECHARGE Command Period
• CWL = CAS Write Latency
• Command Signal modes = 1n indicates a new command may be issued every clock
and 2n indicates a new command may be issued every 2 clocks. Command launch
mode programming depends on the transfer rate and memory configuration.
