40 Installation options
NN47928-302NN47928-302
14 Slide the wall-mount lock to the left (lock position).
15 Use the supplied screw to secure the wall-mount lock into position.
16 Open the cable management door on the wall-mount bracket.
You must replace the door on the standard small system wall-mount bracket.
The replacement door has a notch to accommodate the BSG8ew antenna.
17 Push up on the door to pop the hinges apart and remove the door.
18 Line up the hinges on the replacement door with those on the wall-mount
bracket.
19 Push down on the door to snap the hinges into place.
20 Open the cable management door.
21 Screw the antenna adapter into the antenna position on the BSG8ew.
Cutout detail
