WiFi module replacement 61
Installation
Procedure steps
Step Action
1 Unscrew and remove the two antennas.
2 Use a Phillips screwdriver to remove the screws on either side of the WiFi
module. You will feel the screws disengage when you have sufficiently loosened
them.
3 Gently remove the WiFi module from the faceplate.
4 Slide the BSG12ew/aw/tw
WiFi Replacement Module (NT5S21ZAE6) into the
WiFi module slot.
5 Use a Phillips screwdriver to retighten the screws on either side of the WiFi
module. Do not overtighten the screws.
6 Screw the two antennas back onto the unit.
7 Power up the BSG12ew/aw/tw unit.
End
Verifying the WiFi installation
Use this procedure to verify the installation of the WiFi module in the BSG12ew/aw/tw.
Procedure steps
Step Action
1 Launch an SSH session.
2 Log on to the BSG12ew/aw/tw using the user ID and password.
3 At the prompt, enter the following command:
show sub-system information wifi
4 Verify the status.
The system displays the following status if you installed the unit properly:
WiFi Info:
IpAddress: 169.254.1.3
OperStatus: UP
Firmware Version: <firmware version>
The system displays the following status if you did not install the unit properly:
WiFi Info:
IpAddress: 169.254.1.3
OperStatus: DOWN
Firmware Version: <firmware version>
5 Verify that your wireless-capable PC or laptop can connect with the broadcast
SSID and enable network connectivity.
