Installation
New in this release
The following sections detail the hardware features of the Business Services Gateway 8-port
(BSG8ew) and the Business Services Gateway 12-port (BSG12ew/aw/tw) with Ethernet WAN,
ADSL WAN, and T1/E1 WAN:
• “LEDs” on page 7
• “Power source” on page 7
• “FE LAN ports” on page 7
• “GigE LAN ports” on page 8
• “FXO ports” on page 8
• “FXS ports” on page 8
• “WAN interfaces” on page 8
• “Console port” on page 8
• “WiFi access point” on page 8
• “Desktop mount” on page 8
• “Rack-mount shelf” on page 9
• “Wall-mount bracket” on page 9
• “Checking for software upgrades” on page 9
LEDs
The LEDs indicate the status of the power, system, and the ports. For more information, see “LED
functionality” on page 25.
Power source
The BSG8ew is powered by a 60 W 12 V DC power adapter with a power supply cord. The
BSG12ew/aw/tw is powered by a 132 W 48 V DC rear faceplate connected using a 4-pin DIN
connector. For more information, see “Power supply” on page 22, “Connecting power to the
BSG8ew” on page 45, and “Connecting power to the BSG12ew/aw/tw” on page 46.
FE LAN ports
The FE LAN ports connect the BSG to the LAN. For more information, see “LAN port LEDs” on
page 26.
