9 Press [Restart Computer].
10 Select “Windows NT Workstation Version 4.00” and
press Enter .
11 Following the display, press Ctrl + Alt +
Del . Input the password set in step 6 and select
[OK], then select [Close] at the [Welcome] display.
As the computer starts up, it will be necessary to
input the password set in step 6 .
12 Install Intel (R) Speed Step (TM).
(At the [Welcome], select [Next]. When the installa-
tion completes, select [No, I will restart my computer
later], select [Finish].)
13 Follow the on-screen instructions and install ESS
Allegro1 Utility.
(At the [Welcome], select [Next]. Confirm [Upgrade
Drivers] is selected, then select [Next]. When the in-
stallation completes, select [No. I will restart my
computer later], then select [Finish].)
14 Follow the on-screen instructions and install Phoenix
APM 2.0 for Windows NT.
When the installation completes, select [Don't Restart
Now].
15 Follow the on-screen instructions and install Phoenix
Card Executive™ for Windows NT.
When the installation completes, select [Restart Now].
16 The [Begin Logon] display will appear. Perform the
operation in step 11 .
17 Select [Next] at the [Card Executive 2.0 for NT Diag-
nostics].
18 Select [Next], then select [Finish].
Windows will restart.
19 The [Begin Logon] display will appear. Perform the
operation in step 11 .
20 Select [Change] in [Start] - [Settings] - [Control Panel]
- [Mouse] - [General].
21 Press [Have Disk] and input [c:\util\drivers\mouse], then
press [OK].
22 Confirm [touchpad] is selected, then press [OK].
If [Confirm Device Install] is displayed, press [Yes].
23 Press [Close].
The display will ask you to restart Windows, press
[Yes].
NOTE
Windows NT
About Differences between Factory Condition and After
Reinstallation
The condition after reinstallation differs in the following
points with the factory condition.
During startup, the ATI video driver’s [DeskTop Help]
is displayed (remove the check mark for [Show this
screen next time you start Windows]).
The ATI icon is displayed in the task tray (remove the
check mark for [Enable ATI Taskbar Icon] in [Display
Properties] - [Options]).
After the reinstallation, the free space on the hard disk
is taken as the primary partition (delete the free space
in [Start] - [Programs] - [Administrative Tools (Com-
mon)] - [Disk Administrator]).
It takes several minutes for the necessary files to
be copied. If the computer enters the ECO mode,
the power to the LCD is automatically turned off.
In this case, press a key unrelated to the direct
triggering of a selection, like Ctrl .
NOTE
24 Double-click the [Internet Explorer] icon to install Internet
Explorer.
25 Select [I accept the agreement], then select [Next].
26 Select [Install Minimal, or customize your browser], then select
[Next].
27 Select [Full] by clicking , then select [Next].
28 At the [Restart Computer], select [Finish].
29 Set the correct settings for all items in [Control Panel]-[Re-
gional Settings] and [Date/Time] etc.
30 Install the Acrobat Reader 4.0. ( page 18)
