5 - Appendice
User Guide - N56815740110
Page 5-6
No reproduction or communication without the written consent of SAGEM SA
5.3 Technical specifications
5.3.1 Equipment specifications
Interface specifications
USB
Bit rate
< 12 Mbit/s
Standard USB 1.0
Data Asynchronous
Transmission mode Bidirectional
Connector
USB - Type B
ADSL
Transmission code
Standards supported (*)
Maximum upstream rate
Maximum downstream rate
Latency
DMT (Discrete Multi Tone)
T1.413 Ed.2
G.992.1 (G.dmt)
G.992.2 (G.lite)
G.994.1 (Handshake ADSL)
896 kbit/s
8160 kbit/s
Simple latency (Fast or Interleave)
Connector RJ11 (pins 3 and 4)
Mechanical specifications
Dimensions (mm) Width : 188 mm
Depth : 142 mm
Thickness : 45 mm
Weight 800 g
Installation
Desktop
(*) Depending on the installed software.
