Design and specifications are subject to change without prior notice.
General
Model Name SyncMaster 171MP
LCD Panel
Size 17.0 inch (Diagonal)
Display area 338 (H) x 270 (V)
Pixel Pitch 0.264 (H) x 0.264 (V)
Type a-si TFT active matrix
Viewing Angle 80/80/80/80 (L/R/U/D)
(Depending on the panel manufacturer, the viewing angle may be different
from this spec.)
Synchronization
Horizontal 30 ~ 81 kHz
Vertical 56 ~ 85 Hz(~XGA), 60 ~76 Hz(SXGA)
Display Color
16,777,216 Colors
Resolution
Optimum resolution 1280 x 1024 @ 60Hz
Maximum resolution 1280 x 1024 @ 76Hz
Input Signal
Sync.
Separate: TTL, P. or N.
Composite: TTL, P. or N.
Sync-on-green: 0.3 Vp-p, N.
Video signal 0.7 Vp-p @ 75 ohm
TV / Video
Color system PAL, SECAM, NTSC 4.4
Sound system B/G, D/K, I, L, L'
Video format CVBS, S-VHS
Video
Color system PAL / NTSC / SECAM
Maximum Pixel Clock
135 MHz
Power Supply
Input AC 90 ~ 264 V (50/60 Hz)
Ouput DC 12V / 4.5A
Power Consumption
Maximum 52W
Power Saving Less than 3W
Dimensions (WxHxD) / Weight
Monitor body 412.0 x 408.0 x 58.5 mm / 4.7 kg
With stand 412.0 x 418.0 x 203.0 mm / 5 kg
When folded 412.0 x 472.0 x 58.5 mm / 5 kg
