Sony FX52L Projector User Manual



11
Location and Function of Controls
Overview
l Adjuster
Use the adjusters to keep the projector
level if it is installed on an uneven
surface.
Adjust the height so that the projector
becomes level. The projector is raised by
turning the adjusters clockwise, or it is
lowered by turning them
counterclockwise.
m Air filter
For details, see “Cleaning the Air
Filter” on page 43.
To maintain optimal performance, clean
the air filter periodically.
a LENS CONTROL key
Enters the focus, zoom or shift
adjustment mode. Next adjust them
using the arrow keys. Each time you
press the key, the mode changes to
LENS FOCUS, LENS ZOOM and
LENS SHIFT in order. The mode
currently selected is displayed on the
screen.
LENS FOCUS: Enters the focus
adjustment mode. Next adjust the
focus using the arrow keys. Press the
M or , key to focus on a picture
further back, and the m or < key to
focus on a forward picture. The LENS
FOCUS does not work when you
attach the optional lens.
LENS ZOOM: Enters the zoom
adjustment mode. Next adjust the
picture size using the arrow keys.
Press the M or , key to enlarge the
picture size, and the m or < key to
reduce it. The LENS ZOOM does not
work when you attach the optional
lens.
LENS SHIFT: Enters the shift
adjustment mode. Next adjust the
vertical position of the picture using
the arrow keys. Press the M or , key
to move the picture upward, and the m
or < key to move it downward.
Note
Control Panel
RESET
LENS CONTROL
POWER SAVING ON/STANDBY
MENU
TEMP/FAN
ENTER
APA
LAMP/COVER
INPUT
12 3
456789
