Additional Information
Model name1[KP-53HS10] Model name2[KP-61HS10]
[4-074-163-11 (1)]
Specifications
Projection system
3 picture tubes, 3 lenses, horizontal in-line system
Picture tube
7-inch high-brightness monochrome tubes (6.3 raster size),
with optical coupling and liquid cooling system
Projection lenses
High performance, large diameter hybrid lens F1.1
Television system
American TV standard
Channel coverage
VHF: 2–13/UHF: 14–69/CATV: 1–125
Antenna
75 ohm external terminal for VHF/UHF
Screen size (measured diagonally)
53 inches (KP-53HS10)
61 inches (KP-61HS10)
Inputs/outputs
VIDEO 1/3 IN
VIDEO 2 INPUT
S VIDEO IN (4-pin mini DIN):
Y: 1 Vp-p, 75-ohms unbalanced, sync negative
C: 0.286 Vp-p (Burst signal), 75 ohms
VIDEO (phono jack): 1 Vp-p, 75-ohms unbalanced, sync
negative
AUDIO (phono jacks): 500 mVrms (100% modulation),
Impedance: 47 kilohms
VIDEO 4 IN
S VIDEO IN (4-pin mini DIN):
Y: 1 Vp-p, 75-ohms unbalanced, sync negative
C: 0.286 Vp-p (Burst signal), 75 ohms
VIDEO (phono jack): 1 Vp-p, 75-ohms unbalanced, sync
negative
Y: 1 Vp-p, 75 ohms, sync negative
P
B
: 0.7 Vp-p, 75 ohms
P
R
: 0.7 Vp-p, 75 ohms
AUDIO (phono jacks): 500 mVrms (100% modulation),
Impedance: 47 kilohms
VIDEO 5 (DTV) IN
Maximum scanning rate: 1080i
Y: 1 Vp-p, 75 ohms, negative or tri-level sync
P
B
: 0.7 Vp-p, 75 ohms
P
R
: 0.7 Vp-p, 75 ohms
or
G: 0.7 Vp-p, 75 ohms
B: 0.7 Vp-p, 75 ohms
R: 0.7 Vp-p, 75 ohms
HD: 0.5–5 Vp-p, 2.2 kilohms
VD: 0.6–5 Vp-p, 2.2 kilohms
Note:
The VIDEO 5 (DTV) IN jacks are not compatible with a
computer’s 5BNC (R/G/B/HD/VD) video output connectors.
AUDIO (phono jacks): 500 mVrms (100% modulation),
Impedance: 47 kilohms
SELECT OUT
VIDEO (phono jack): 1 Vp-p, 75-ohms unbalanced, sync
negative
AUDIO (phono jacks): 470 mVrms (100% modulation),
Impedance: 47 kilohms
AUDIO (VAR) OUT
(phono jacks): 700 mVrms (100%
modulation)
AUDIO (FIX) OUT
(phono jacks): 500 mVrms (100%
modulation)
CONTROL S IN/OUT:
minijacks
Speaker
Front (Tweeter): 66 mm (2
5
/
8
”)
×
2
Front (Woofer):
130 mm (5
1
/
8
”)
×
2 (KP-53HS10)
160 mm (6
3
/
8
”)
×
2 (KP-61HS10)
Speaker output
Front: 20 W
×
2
Power requirement
120 V AC, 60 Hz
Power consumption
In use (Max.): 240 W
In standby: 1 W
Dimensions (W/H/D)
1,218
×
1,459
×
635 mm (48
×
57
1
/
2
×
25 inches)
(KP-53HS10)
1,372
×
1,558
×
670 mm (54
1
/
8
×
61
3
/
8
×
26
1
/
2
inches)
(KP-61HS10)
Mass
84 kg (185 lbs 3 oz) (KP-53HS10)
102 kg (224 lbs 14 oz) (KP-61HS10)
Supplied accessories
Remote control RM-Y902 (1)
Batteries size AA (R6) (2)
Optional accessories
Connecting cables
RK-G34, RK-74A, RKG-69HG, VMC-10HG,
VMC-720M, VMC-810S/820S, YC-15V/30V
U/V mixer EAC-66
Design and specifications are subject to change without
notice.
