4.15 FL Inverter Board 4 Replacement Procedures
4.15 FL Inverter Board
Removing the FL Inverter Board
Remove the FL inverter board according to the following procedures and Figures 4-33 and 4-
34.
1. Remove the M2.5x4.5 black flat-head screw.
Figure 4-33 Removing the FL inverter board
2. Raise the FL inverter board and disconnect the LCD/FL cable from LCD/FL
connecter.
3. Disconnect the HV cable from HV connecter and remove the FL inverter board.
Satellite A60/ Pro A60 Maintenance Manual 4-49
