2.2.2. Con nec ti on to a vac uum receiver unit SSK-05 1, 3, 5, & 30
»
Electrical connections are to be made by trained personnel
only.
Observe the regulations of your local Electricity Board.
All work is to be carried out with the equipment
disconnected from electric power and compressed air
supply.
The power consumption value of the SKW is approx. 15 Watts.
The operating voltage of the SKW is 24 V.
Lay a cable (min. 3 x 1 mm
2
) from the single conveyor unit to the SKW.
Install the supplied plugs.
Install the plug of the SKW at the plug connector of the single conveyor control
unit.
Observe the operating instructions of the vacuum receiver unit.
2.2.3. Con nec ti on to a con vey ing sys tem controller
»
The electrical connection to a conveying system controller
may only be made by skilled personnel authorized by
Sterling.
Other persons are not permitted to install electrical
connections.
046-3MS
SKW
In stal la ti on in struc tions 19
