COMMunications Menu (Sess 1 - EIA) 25
ENTER:menu ↑ ↓ :line ← → SPACE:select S-SETUP:exit CTL-SETUP:SES#1
Mode [Block, H-Blk, FDX/Line, HDX/Echo]
Four selections are available for defining communication protocol.
Baud Rate [38400, 19200, 9600, 4800, 2400, 2000, 1800]
Various baud rates are available to match the data rate for your computer system.
Parity [None, Odd, Even]
Multiple selections are available to meet the requirements of your host computer.
Parity Check [Yes, No]
When Yes is selected, an asterisk (*) symbol will be displayed on your screen at any
character position where an error in parity is detected by the terminal on incoming
data.
Data Bits [7, 8]
Select 7 or 8 bit character operation.
Stop Bits [1, 2]
Select to append 1 or 2 stop bits at the end of a character.
Xon/Xoff [None, DTR, DC1/DC3, Both]
Select DTR, DC1/DC3 or both for data flow control. Flow control must be used
when using smooth scroll.
Pace [00]
Relative amount of delay time between characters during transmission to host (00-99).
Use right arrow to increase value and left arrow to decrease value.
When transmitting large character strings of function key data, this feature will be
useful in preventing any characters from being lost during transmission to the host.
Terminator [US/CR, CRLF/ETX]
This field sets the end of line/end of page characters for block mode.
XPC [Off, On]
Set data flow control for PC Term Operation. This option modifies the Xon/Xoff
characters.
