Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)

CONFIGURING the SERVER

Table 14 PCIe Card Compatibility

PCIe Cards

Twinax

Cables

Cisco SFP Modules

SFP-10G-SR DS-SFP-FC8G-SW

Converged Network Adapters (CNAs)

UCSC-PCIE-BSFP

(Broadcom 57712 Dual Port 10Gb SFP+ w/TOE iSCSI)

Yes Yes No

UCSC-PCIE-CSC-02

(Cisco VIC 1225 Dual Port 10Gb SFP+ CNA)

Yes Yes No

UCSC-PCIE-C10T-02

(Cisco VIC 1225T Dual Port 10GBaseT CNA)

Yes No No

UCSC-PCIE-ESFP

(Emulex OCe11102-FX dual-port 10 GbE FCoE CNA (Gen 3 CNA))

Yes Yes No

UCSC-PCIE-QSFP

(QLogic QLE8242-CU dual-port 10 GbE FCoE CNA)

Yes Use Qlogic SFP

UCSC-PCIE-B3SFP

(Broadcom 57810 10Gb A-FEX SFP+

Yes Yes No

UCSC-PCIE-Q8362

(Qlogic QLE8362 dual-port 10 GbE FCoE CNA)

Yes Use Qlogic SFP

Network Interface Cards (NICs)

N2XX-ABPCI01-M3

(Broadcom 5709 Dual-Port Ethernet PCIe Adapter for M3

Servers)

Yes No No

N2XX-ABPCI03-M3

(Broadcom 5709 Quad Port 10/100/1Gb NIC w/TOE iSCSI for M3

Servers

Use RJ45 Ethernet cable

N2XX-AIPCI01

(Intel X520 Dual Port 10Gb SFP+ Adapter)

Yes Use Intel SFP

UCSC-PCIE-ITG

(Intel X540 Dual Port 10GBase-T Adapter)

Yes No No

UCSC-PCIE-IRJ45

(Intel i350 Quad Port 1Gb Adapter

Use RJ45 Ethernet cable

UCSC-PCIE-BTG

(Broadcom 57712 Dual Port 10GBASE-T w/TOE iSCSI)

Yes No No

Host Bus Adapters (HBAs)

N2XX-AEPCI03

(Emulex LPe 11002 Dual Port 4Gb Fibre Channel HBA
