Chapter 9 Specifications
55
Chapter 9
Specifications
9.1 General specifications
Item CLP-9001 CLP-9301
Printing method Thermal Transfer/Direct Thermal
Printhead resolution 203 DPI (8 dots/mm) approx 300 DPI (12 dots/mm) approx
Maximum print width 104 mm (4.1 in) 105.7 mm (4.16 in)
Print length 6.5 mm 1,016 mm (0.25 40 in) 6.5 mm 762 mm (0.25 in 30 in)
Print speed 2 12 IPS* 2 8 IPS
Media Max. media roll diameter: 250 mm (9.84 in) for inward-wound media
203 mm (8 in) for outward-wound media
Max. media width: 115 mm (4.53 in)
Media pitch detections Adjustable transparent and reflective sensors
Ribbon Max. ribbon length: 360 m (1,181 feet)
Max. ribbon outer diameter: 85 mm (3.35 in)
Bar codes Code 39/93/128 (A/B/C), EAN 8/13, UPC-A/E, UPC-2&5-Digit
Codabar (NW-7), Interleaved 2 of 5, UCC/EAN 128
PDF-417, UPS MaxiCode, DataMatrix
Indications LCD: 8 columns x 2 rows. LEDs: POWER and READY
Control keys Setup keys (six): MODE, MENU, SELECT, EXIT, UP and DOWN
Execution keys (four):
STOP, FEED, PAUSE and REPEAT
Graphic data 7-bit ASCII, 8-bit HEX, PCX and BMP
Interfaces Standard: RS-232C serial (max: 115.2 kbps) and Centronics parallel
Optional:
USB, Ethernet and IEEE 1284 ECP
Options By factory: Peeler with rewinder
By dealer (reseller): Standard cutter, Heavy-duty cutter, USB, Ehernet
and IEEE 1284 ECP
Power input voltage 120V: -10%+6%, 2.6A, 60HZ (U.S.A., Canada)
220V 240V: -10%+6%, 1.5A, 50/60HZ (Europe)
Power consumption Typical operating: 235VA, Stanby: 50VA
Operating temperature and
humidity
5 40ºC (41 104ºF), Rh25~85% (non-condensing)
Outer dimensions 243W x298H x 472D mm (9.6W x 11.7H x 18.7D in), approx
Weight 16 kg (35.24 lb) approx, excluding media and ribbon
Standards 120V: UL1950 CSA: No. 950 FCC: Class A
220V 240V: EN60950, EN55024, EN61000-3-2, EN61000-3-3
* 10 IPS for media width of less than 2 inches.
