Chapter 9 Specifications
−
60
−
9.4 Adjustable sensor
The required detection position can be set with the adjustable sensor. The adjustable sensor mechanism
is illustrated below.
Media Sensor
Setup
Guide
Setup
Voltage
Voltage
Level
Variable
Voltage
Black Mark Reflective
No Mark
area
2.1V
1.7V or
less
Gap
No Gap
area
1.05V
1.5V or
more
Hole
including corner ‘R’
Trans-
parent
No Paper 2.5V
1.5V or
more
0.0V −
3.3V
Paper guide
115mm (4.5”): maximum paper width
0.8mm (0.03”) fo
r
Transparent senso
r
3.95mm (0.16”) fo
r
Reflective senso
r
57.8mm (2.27”):
sensor adjustable range
57.8mm (2.27”):
sensor adjustable range
