—41—
Nachstehend finden Sie eine Darstellung der einzelnen Speicherschalter. (Die
werksseitigen Einstellungen sind schattiert dargestellt.)
Schalter Nr. Funktion OFF ON
MSW1-1 Power ON Info
Valid Not Send
MSW1-2 Buffer Size
4K bytes 45 bytes
MSW1-3 Busy Condition
Full/Err Full
MSW1-4 Receive Error
Print“?” No Print
MSW1-5 CR Mode
Ignored LF
MSW1-6 Reserved
Fixed —
MSW1-7 DSR Signal
Invalid Valid
MSW1-8 Init Signal
Invalid Valid
MSW2-1 Reserved —
Fixed
MSW2-2 Auto Cutter Invalid
Valid
* MSW2-3 Spool Print
Invalid Valid
MSW2-4 Full Col Print LineFeed
WaitData
MSW2-5 Resume aft PE
Next Top
MSW2-6 Reserved
Fixed —
MSW2-7 Reserved
Fixed —
MSW2-8 PNE Sensor
Valid Invalid
MSW3-1 Resume Cttr Err
Valid Invalid
MSW3-2 PE signal by PNE Valid
Invalid
MSW3-3 Parallel 31 Pin
Valid Invalid
MSW3-4 Reserved
Fixed —
MSW3-5 Reserved
Fixed —
MSW3-6 Reserved
Fixed —
MSW3-7 CBM1000 Mode
Invalid Valid
MSW3-8 Resume Open Err
Close Command
MSW4-1 Reserved
Fixed —
MSW4-2 Reserved
Fixed —
MSW4-3 Feed&Cut at TOF Invalid
Valid
MSW4-4 Reserved
Fixed —
MSW4-5 Reserved
Fixed —
MSW4-6 Reserved
Fixed —
MSW4-7 Reserved
Fixed —
MSW4-8 Partial Only Invalid
Valid
MSW5-1 Buzzer
Valid Invalid
MSW5-2 Line Pitch
1/360 1/406
MSW5-3 USB Mode Virtual COM
Printer Class
MSW5-4 Reserved
Fixed —
MSW5-5 Reserved
Fixed —
MSW5-6 Reserved
Fixed —
MSW5-7 Reserved
Fixed —
MSW5-8 Reserved
Fixed —
