Make sure the following items are included with your printer.
Model numbers indicate printer features according to the following system.
Note:
*:AC power cord, serial I/F screw, firmware and other specifications vary according to markets.
1.2 Unpacking
z Printer: 1
z Interface cover: 1
z AC power cord: 1
z Power switch cover: 1
z Sample paper roll: 1 roll
z CD-ROM: 1
z Quick Start Guide: 1
z AC adapter
*1:1
z USB cable
*2:1
Notes:
*1: CT-S601A only
*2: USB interface types only
In designated markets
1.3 Model Classification
CT-S601S
(Built-in power supply type)
36AD3 AC adapter built in
AC power cord
Power switch
cover
USB cable
Quick Start
Guide
CT-S601A
(AC adapter type)
AC adapter
(36AD2)
AC power
cord
Quick Start
Guide
CD-ROM
USB cable
Sample
paper roll
Interface cover
Interface coverCD-ROM
Sample
paper roll
Power switch
cover
CT - S601S 3 RS E - BK - P L M1
Power supply
DC:No power source
S: Built-in power supply type
A: AC adapter type
Interface
PA: Parallel
RS: Serial RS-232C
UB: USB only
UH: USB with hub
ET: Ethernet (standard type)
ES: Ethernet (multi-function type)
UP: Powered USB
Market:
*
J: Japanese E: Europe/Asia
U: North America
C: China
Paper width
3: 3 inch (80/83 mm)
2: 2 inch (58/60 mm)
Body case color
WH: Cool white
BK: Black
PNE sensor
:No
P: PNE sensor
Label
:No
L: Label printing
BM sensor
:No
M1: Left side
M2: Right
side
